automatic china new style twin shaft concrete mixer js1000 litre

 js1000 mixer Product Application

automatic china new style twin shaft concrete mixer js1000 litre  can be used independent and also be used as the part of the concrete batching plant,it can apply to kinds of construction site and precast parts factory.

twin shaft concrete mixer js1000 Detailed Images

twin shaft concrete mixer js1000




Name: JS1000

Brand: CO-NELE

Original: Shandong China

The whole mixer body is bored by the boring machine, to keep the concentric degree of the mixing axle.



The rubber sealing gasket of the axle end seal is installed at side of the mixing arm, normally it can mixing 200 thousand time without mortar leakage.

JS1000 concrete mixer





The discharging opening adopts arch structure with the Scraper,the machine can work for arch leveling and work in steady,to prevent the material bejammed by the discharging opening.

discharging opening

The lubrication and seal of the axle end adopt the electrical concentrated oil pump to lubricate automatically.

Hydraulic pumping stationLubrication pump

Model:JS1000
Charge volume(L):1500
Discharge volume(L):1000
Productivity(m3/h):≤50
Aggregate diameter (mm):80/60
Mixing blade speed(r/min):25.5
Mixing blade quanity”20
Mixing motor  model:37kw
Water pump power (kw):3
Hopper hoisting speed(m/min):21.9
Overall dimension (mm):2780*2080*1965
Total weight (kg):5000
Discharge height (mm):According to your choice.

Pre-Sales Service

  * Inquiry and consulting support.

  * View our Factory.

After-Sales Service

  * Training how to instal the machine, training how to use the machine.

  * Engineers available to service machinery overseas.
